The APsystems Microinverter

APsystems microinverters mark a breakthrough in solar technology, making PV arrays more powerful, smart, bankable, cost effective and safe.

Conventional “string” systems only operate as efficiently as the lowest-performing module, meaning reduced output from a shadow or leaf on one module cuts output across all modules in the array.

The APsystems microinverter is smarter.

Our microinverter technology individually monitors and maximizes power generation for each module in the array, boosting system efficiency by up to 20 percent. One APsystems unit handles two PV modules, lowering installation and balance-of-system costs.

All APsystems microinverters are engineered to comply with NEC 2014 requirements for Rapid Shutdown out of the box, ensuring safety of system installers and emergency responders.

The APsystems Microinverter Models

APsystems YC500i with EnergyMax

The APsystems YC500i with EnergyMaxTM is a grid-tied microinverter with intelligent networking and monitoring systems to ensure maximum efficiency. Highly dependable and cost effective, the YC500i with EnergyMaxTM is optimized to accommodate today’s high output PV modules effectively with up to 548W output and dual MPPT. An integrated ground allows for rapid installation for installers who prefer trunk cable architecture. Half the inverters and half the installation time means real cost savings for residential and commercial customers.

  • High output microinverter with integrated ground
  • Single unit connects two solar modules
  • Peak output power 548W
  • Individual MPPT for each module
  • PLC communication & free monitoring
  • Ideal for today’s high output PV modules
apsystems-yc500sm
apsystems_yc500i-illustration
yc500i_update_front_trunk_cmyk
APsystems YC500A

Our flagship microinverter, the bestselling YC500 microinverter handles two PV modules simultaneously with dual MPPT. Up to 14 solar modules (7x YC500s) can be installed in a string with a single 20A breaker.

  • Maximum Power Output: 500W (from two solar modules)
  • Individual MPPT for each panel
  • Peak Efficiency: 95.5%
  • Dimensions: 8.6″ (220mm) x 5.4″ (160mm) x 1.37″ (29mm)
  • Weight: 5.5 lbs. (2.5kg)
  • Up to 14 solar modules (7x YC500s) in a string with a 20A breaker
  • 10 and 25 year warranties available
  • Designed to operate in challenging real-world conditions from -40 F to 149 F.
apsystems-yc500sm
apsystems_yc500-illustration
APsystems-YC500-photo-diagram
yc500-2panel_diagram
APsystems YC1000-3-48

The world’s first true 3-PHASE 4-panel microinverter!  APsystems YC1000-3

The YC1000 is the industry’s first true 3-phase (phase-balanced & phase-monitored)

solar microinverter, handling 277Y/480V grid voltages with 900 watts maximum output, ZigBee communication and an integrated ground. Up to 11 units (44 modules total, 60- or 72-cell) can be linked in a single 15A circuit.

This groundbreaking technology is only available from APsystems.

    • 900w AC output
    • 3 phase output (phase-balanced & phase-monitored)
    • 277Y / 480V
    • ZigBee
    • 11 units / string (up to 44 PV modules)
    • Weight: 8.8 lbs. (4kg)
    • 10 and 25 year warranties available
APsystem-newYC1000-web
apsystems_yc1000-illustration
apsystem-YC1000sm-web
yc1000-ecu-z_4pv_diagram2
APsystems-YC1000-4panels-side-sm-1030x928
APsystems YC1000-3-208

The world’s first true 3-phase (no phase balancing) microinverter is also available in a 208V configuration, also with 900 watts AC maximum output, ZigBee communication and an integrated ground. Up to four YC1000-3-208 units (16 modules total, 60- or 72-cell) can be installed on a single 15A circuit.

This groundbreaking technology is only available from APsystems.

  • 900w AC output
  • 3 phase output (no phase balancing)
  • 208V
  • ZigBee
  • 4 units / string (up to 16 PV modules)
  • Weight: 8.8 lbs. (4kg)
  • 10 and 25 year warranties available
APsystem-newYC1000-web
apsystems_yc1000-illustration
apsystem-YC1000sm-web
yc1000-ecu-z_4pv_diagram2
APsystems-YC1000-4panels-side-sm-1030x928
